Isolated RS232 To RS232 Repeater
Features and Specification
* Isolated RS485 Signals up to 2.5KVrms
* Isolated RS485 Power up to 1KVrms.
* Supports Auto-Direction Control. No flow
control signal required.
- actual baud rate varies on the cable length
– also depends on the other devices connected
in the RS485 network
* Works with all type of industrial equipment
– PC, PLC, SCADA, HMI, AC/DC Drives,
Genset, UPS, Development Kits, etc.
* RS485 Rx and Tx light indications for easy
visibility and troubleshooting
* ESD protection for both RS485 pins
– ±15-kV Human-Body Model (HBM)
– ±8-kV IEC1000-4-2, Contact Discharge
– ±15-kV IEC1000-4-2, Air-Gap Discharge
* Compact design suitable for both DIN Rail and Wall mount
* Dimension in mm – 110 x 74 x 35
* 1 Year Warranty against any manufacturing
defects
